Double-Stage High-Efficiency Vacuum Transformer Oil Purification and Regeneration Plant

Also named: Vacuum Dehydrator, Vacuum Purification System, Oil Degasification

Product Overview

Also named: Vacuum Dehydrator, Vacuum Purification System, Oil Degasification, Regeneration, Recycling

Under effect of heat and electric field, the exposure of insulation oil not only contained trace water, gas, particulate matters, but also acid, sludges, pitches and dissociated carbon.

The use of Vacuum Transformer Oil Purification and Regeneration Plant (VFD-R) is necessary, which will help you maintain optimal oil cleanliness. Therefore, making the most use of your equipment to gain the highest and save your money.


APPLICATION

Transformer Oil Regeneration is adapt to regenerate and activate the deteriorated transformer oil

It is capable of removing the moisture, gas and mechanical impurities as well as eliminating organic acid, sludges, pitches and dissociated carbon in the deteriorated transformer oil which are difficult to be removed by conventional oil purifier plants. After the treatment, the regenerated oil can met the required standard and life span of new insulation oil.


Double-Stage High-Efficiency Vacuum Transformer Oil Purification and Regeneration Plant

NSH provide worldwide commissioning and after-sales service.


PERFORMANCE

OIL SPEC (after treatment)

●Water: ≤ 5 PPM

●Filter Fineness: ≤ 5 µm (or ≤ 1 µm)

● Dielectric: ≥ 65kV~75kV

● Degassing: ≤ 0.1%


Adding VFD with regeneration device, the machine can also treat acid, sludges, carbon and remove color.

● Oil color: better than L=0.5

● Acid Value: ≤ 0.01 MgK0H/g

● Soluble Acid PH value: =5~7

● Dielectric loss tangent tg(90℃)% : ≤0.002


MACHINE SPEC

●Flow rate in L/H: 600 ~ 18,000

● Vacuum range in Mpa: -0.092~-0.099

● Working pressure in Mpa: ≤ 0.2

● Max vacuum range in Pa: ≤ 5

●Temperature range℃: 45 ~80

** Operating voltage: 380 V (50 Hz), 380 V (60 Hz), 400 V (60 Hz), 415 V (50 Hz), 415 V (60 Hz), 220 V (60 Hz), 460 V (60 Hz), etc (customizable)

** The heating power and total power are different with different capacity, please consult sales for more.


OPTIMIZED STRUCTURES

●Dehydration (Degassing) System

●Filtering System

●Regeneration System

●Oil Heating System

●Control panel

●Vacuum pump & Roots pump, screw pump

●Cooling System and Condensing System

●Auto-control and Protection System


PRESENTATIONS OPTIONS

●Base frame with caster wheels

●Metallic enclosure cover on caster wheels

●Metallic enclosure cover on single axletrailer

●Base frame on double axle trailer

●Metallic enclosure cover on double axletrailer

●Metallic enclosure cover and operation room on double axle trailer


Double-Stage High-Efficiency Vacuum Transformer Oil Purification and Regeneration Plant



Sino-NSH Oil Purifier Manufacture Co., Ltd. is a high-tech Company Since 1992 which is engaged in researching, developing and manufacturing lubrication purification equipment, Our products are very popular, if you are interested in our products, please contact us as soon as possible. Email: sales@sino-purification.com

Product Name : Double-Stage High-Efficiency Vacuum Transformer Oil Purification and Regeneration Plant
